1편에서, RESTful API 를 이용한 방만들기, 방 조회 까지의 부분을 다뤘다.
이번 블로그에서는 STOMP를 이용하여 본격적으로 실시간 양방향 통신을 구현하는 방법에 대해 알아보려 한다.
build.gradle.kts(:app)
dependencies {
...
// STOMP protocol client
implementation("com.github.NaikSoftware:StompProtocolAndroid:1.6.6")
// rx
implementation("io.reactivex.rxjava2:rxjava:2.2.21")
implementation("io.reactivex.rxjava2:rxandroid:2.1.1")
}settings.gradle.kts
repositories {
...
maven("https://jitpack.io")
}ApiConstants
object ApiConstants {
...
// WebSocket 엔드포인트
const val WS_BASE_URL = "ws://192.168.0.34:9999/ws-chat-native"
const val WS_BASE_URL_VD = "ws://10.0.2.2:9999/ws-chat-native" // 가상머신
// STOMP 경로
const val STOMP_PUBLISH_PREFIX = "/pub"
const val STOMP_SUBSCRIBE_PREFIX = "/sub"
...
}StompClientManager
/**
* STOMP 프로토콜을 사용한 웹소켓 연결 관리 클래스.
*/
@Singleton
class StompClientManager @Inject constructor() {
private val TAG = "StompClientManager"
private var stompClient: StompClient? = null
// RxJava의 Disposable을 관리하기 위한 컴포지트
private val compositeDisposable = CompositeDisposable()
private val _connectionState = MutableStateFlow<ConnectionState>(ConnectionState.DISCONNECTED)
val connectionState: StateFlow<ConnectionState> = _connectionState
fun connect() {
if (stompClient != null && stompClient?.isConnected == true) {
return
}
val url = ApiConstants.getWebSocketUrl(ApiConstants.isEmulator)
Log.d(TAG, "Connecting to WebSocket: $url")
stompClient = Stomp.over(Stomp.ConnectionProvider.OKHTTP, url)
val headers = listOf(
StompHeader("Origin", "app//com.example.chatapp"),
StompHeader("X-App-Package", "com.example.chatapp")
)
stompClient?.connect(headers)
stompClient?.lifecycle()?.subscribe { lifecycleEvent ->
when (lifecycleEvent.type) {
LifecycleEvent.Type.OPENED -> {
_connectionState.value = ConnectionState.CONNECTED
}
LifecycleEvent.Type.CLOSED -> {
_connectionState.value = ConnectionState.DISCONNECTED
}
LifecycleEvent.Type.ERROR -> {
_connectionState.value = ConnectionState.ERROR
}
else -> {}
}
}?.let { compositeDisposable.add(it) } // Disposable 추가하여 메모리 누수 방지
}
fun disconnect() {
stompClient?.disconnect()
compositeDisposable.clear()
_connectionState.value = ConnectionState.DISCONNECTED
}
fun subscribeToRoom(roomId: String, onMessageReceived: (ChatMessage) -> Unit): Disposable? {
if (stompClient?.isConnected != true) {
_connectionState.value = ConnectionState.ERROR
return null
}
val topicDisposable = stompClient?.topic("$STOMP_SUBSCRIBE_PREFIX/$roomId")?.subscribe({ topicMessage ->
val chatMessage = Gson().fromJson(topicMessage.payload, ChatMessage::class.java)
onMessageReceived(chatMessage)
}, { throwable ->
Log.e(TAG, "Error subscribing to room: ${throwable.message}")
})
// Disposable 관리를 위해 CompositeDisposable에 추가
topicDisposable?.let { compositeDisposable.add(it) }
return topicDisposable
}
fun sendMessage(roomId: String, chatMessage: ChatMessage) {
if (stompClient?.isConnected != true) {
_connectionState.value = ConnectionState.ERROR
return
}
stompClient?.send("${STOMP_PUBLISH_PREFIX}/$roomId", Gson().toJson(chatMessage))?.subscribe({
}, { throwable ->
Log.e("StompClientManager", "Error sending message: ${throwable.message}")
})?.let { compositeDisposable.add(it) }
}
fun onDestroy() {
disconnect()
}
}
enum class ConnectionState {
CONNECTED, DISCONNECTED, ERROR
}ChatRepository
class ChatRepository @Inject constructor(
private val stompClientManager: StompClientManager,
) {
private val TAG = "ChatRepository"
fun connectToSocket() {
stompClientManager.connect()
}
fun disconnectFromSocket() {
stompClientManager.disconnect()
}
val connectionState = stompClientManager.connectionState
fun subscribeToRoom(roomId: String, onMessageReceived: (ChatMessage) -> Unit): Disposable? {
Log.d(TAG, "Subscribing to room: $roomId")
return stompClientManager.subscribeToRoom(roomId) { message ->
Log.d(TAG, "Message received: $message")
onMessageReceived(message)
}
}
fun sendMessage(roomId: String, message: String, sender: String) {
val chatMessage = ChatMessage(
roomId = roomId,
sender = sender,
message = message
)
stompClientManager.sendMessage(roomId, chatMessage)
}
fun enterRoom(roomId: String, username: String) {
val chatMessage = ChatMessage(
roomId = roomId,
sender = username,
message = "$username has entered the room",
type = MessageType.ENTER
)
stompClientManager.sendMessage(roomId, chatMessage)
}
fun leaveRoom(roomId: String, username: String) {
val chatMessage = ChatMessage(
roomId = roomId,
sender = username,
message = "$username has left the room",
type = MessageType.LEAVE
)
stompClientManager.sendMessage(roomId, chatMessage)
}
}RoomViewModel
@HiltViewModel
class RoomViewModel @Inject constructor(
private val chatRoomRepository: ChatRoomRepository,
private val chatRepository: ChatRepository,
) : ViewModel() {
private val _chatMessages = MutableStateFlow<List<ChatMessage>>(emptyList())
val chatMessages: StateFlow<List<ChatMessage>> = _chatMessages
private val _currentRoom = MutableStateFlow<ChatRoom?>(null)
val currentRoom: StateFlow<ChatRoom?> = _currentRoom
private val _messageText = mutableStateOf<String>("")
val messageText: State<String> = _messageText
private val _username = mutableStateOf<String>(UUID.randomUUID().toString())
val username: State<String> = _username
private val _isLoading = MutableStateFlow(false)
val isLoading: StateFlow<Boolean> = _isLoading.asStateFlow()
private val _error = MutableStateFlow<String?>(null)
val error: StateFlow<String?> = _error.asStateFlow()
val connectionState = chatRepository.connectionState
private var messageSubscription: Disposable? = null
init {
connectToSocket()
}
fun connectToSocket() {
chatRepository.connectToSocket()
}
fun disconnectFromSocket() {
messageSubscription?.dispose()
chatRepository.disconnectFromSocket()
}
fun updateMessageText(newText: String) {
_messageText.value = newText
}
fun joinRoom(roomId: String, username: String) {
viewModelScope.launch {
try {
val room = chatRoomRepository.getRoom(roomId)
_currentRoom.value = room
messageSubscription?.dispose()
_chatMessages.value = emptyList()
messageSubscription = chatRepository.subscribeToRoom(roomId) { message ->
viewModelScope.launch {
val currentMessages = _chatMessages.value
val newMessages = currentMessages + message
_chatMessages.value = newMessages
Log.d("RoomViewModel", "Updated messages list, size: ${newMessages.size}")
}
}
chatRepository.enterRoom(roomId, username)
} catch (e: Exception) {
Log.e("ChatRoomViewModel", "Error joining room: ${e.message}")
}
}
}
fun sendMessage(message: String, username: String) {
_currentRoom.value?.let { room ->
chatRepository.sendMessage(room.roomId, message, username)
}
}
fun leaveRoom(username: String) {
_currentRoom.value?.let { room ->
chatRepository.leaveRoom(room.roomId, username)
messageSubscription?.dispose()
messageSubscription = null
_currentRoom.value = null
_chatMessages.value = emptyList()
}
}
override fun onCleared() {
super.onCleared()
messageSubscription?.dispose()
chatRepository.disconnectFromSocket()
}
}
